Speed Cushion - 75mm High.
CODE:
Our 75mm-high Speed Cushion is a heavy duty speed calming device used to slow trucks and other heavy vehicles to less than 5km/h.
Unlike Speed Humps, Speed Cushions are a low-impact speed calmer – their longer profile spreads the weight across the ground making this a durable option for industrial areas where heavy vehicles – carrying heavy loads – are crossing regularly.
Designed to simulate the effect of typical asphalt humps, Speed Cushions are also effective for slowing cars and utes in addition to trucks and larger vehicles.
To slow vehicles to 10-20km/h, check out our 50mm High Speed Cushion.
Key Features
- Slows cars and trucks in shared areas
- Disperses the weight load making for a less abrupt bump
- Tongue-and-groove interlocking rubber modules for increased strength and fast installation
- Fully modular design to build the desired length for your situation
- Anti-skid design
- Bolt down application makes for easy removal or relocation if required
- Middle sections feature hi-vis yellow panels
- Forklift-passable
- 2 fastener types available depending on your application (see options below)
Technical Specifications
- Material: Heavy duty recycled rubber
- Colour: Black with hi-vis yellow panels
- Centre Modules: 500(W) x 1100(L) x 75(H)mm
- End Caps: 250(W) x 1100(L) x 75(H)mm
How Sizing Works
Width is the direction extending across the road (kerb to kerb), whereas length is the distance the vehicle travels over the hump (front wheel to back wheel).
Because centre modules are 500mm wide and end caps are 250mm wide, 1m lengths can be achieved i.e., if your desired width is 2m, you would use 3 x 500mm centre modules and 2 x 250mm end caps.
If you have any questions about choosing your desired width, please enquire below and our team will be more than happy to assist.
Options
Videos
Spec Sheets
Options
Videos
Speed Cushions | Overview
Speed Humps vs Cushions vs Cushion Pads – What’s the difference?
Speed Calmers | Range Overview
Spec Sheets
FAQs.
Are Speed Cushions suitable for heavy vehicles such as trucks carrying freight containers?
How does this product adapt to different vehicle sizes?
Is this system suitable for routes used by forklifts?
Can the speed control system be tailored to specific road dimensions?
How visible is the system to drivers?
Is the system difficult to install or move?
